Low Resistance Bag Filter Media
Product Introduction
Low resistance bag filter media is composed of electrostatic fibers and a low resistance filter layer. The material can increase air circulation rate, lower initial resistance, improve dust loading capacity and reduce energy consumption, while at the same time maintaining filtering efficiency.
Some of the clear benefits of this are the lessening of damage to the environment due to decreased energy usage, and the resultant lowering of energy bills. Low resistance bag filter media is a cost-efficient way for customers to find long-lasting solutions for bag filter needs.
The material conforms to the latest classifications of EN779:2012 standards and can be widely used in hotels, hospitals, high-speed trains, cleaning equipment and new air systems.
Product Performance
- Low initial resistance can improve material’s dust loading capacity and increase the service life of filter.
- Low initial resistance can improve material’s dust loading capacity and increase the service life of filter.
-
Being of low resistance, it can significantly reduce wind resistance of fan to lessen the noise and hence, create a comfortable environment.
Notification
For customers’ ease and comfort, Handanhy can supply sonic sewed filter bags, endless rolls or individual bags.
Real filters come in various configurations and net filtration media are all different. The efficiency of amended filters may vary from media tests. Our efficiency grade can be applied to most bag filters in general designs, but may not be correct for some specially-designed filters; for example, filters with very short bag lengths or very few pockets. The efficiency grade of specially-designed filters should be tested and recommended by filter manufactures.
Product Technical Specification
| Type | Pressure Drop (TSI 8130 NaCl, 0.3µm@ 32L/min.dm²) Pa | Efficiency (TSI 8130 NaCl, 0.3µm@ 32L/min.dm²) % | Pressure Drop (TSI 8130 NaCl, 0.3µm@ 85L/min.dm²) Pa | Efficiency (TSI 8130 NaCl, 0.3µm@ 85L/min.dm²) % | Basic Weight g/m² |
|---|---|---|---|---|---|
| HY-D-F5 | 4 | 50 | 14 | 33 | 97 |
| HY-D-F6 | 6 | 65 | 20 | 43 | 127 |
| HY-D-F7 | 13 | 88 | 37 | 60 | 147 |
| HY-D-F8 | 18 | 95 | 53 | 74 | 155 |
| HY-D-F9 | 22 | 97 | 64 | 85 | 159 |
For customers’ convenience, Hengyong can supply sonic sewed filter bags, endless roll or individual bags.
Real filters are in various configurations and the net filtration media are all different. The efficiency of an end filter may vary from media tests. Our efficiency grade can be applied to most bag filters in general designs, but may not be correct for some specially designed filters, for example, filters with very short bag length or very few pockets. The efficiency grade of special designed filters should be tested and suggested by filter manufactures.
