Activated Carbon Composite Filter Media

Activated Carbon Composite Filter Media

Product Introduction

Activated Carbon Composite Filter Media can effectively remove formaldehyde, absorb small particles in the air and has anti-bacterial properties. Due to its high particle filtration efficiency and ability to absorb odors and chemical vapors, activated carbon is perfect for use in filter media. Its absorption capabilities are greater than those of other carbon loaded products. It is also widely used in industry, medicine and defence.

The material makes use of high-grade granular carbon, without toner, preventing secondary pollution. The basic fabric, with low resistance filter and high efficiency, helps to reduce circulation energy consumption in air filtration. The overall performance is superior to other factories, and the product can be tailored to the requirements of the customer in terms of weight, thickness and color. The activated carbon composite filter material can be used in air purifiers, air conditioners, automotive filters and other products.

Product Performance

  • Quickly removes benzene, formaldehyde, odorous gas and other harmful gases, wherever it is brought into effect.

  • Double-effect and multi-effect function helps to achieve very clean levels of air ventilation.

  • Choice of different performance granular carbon is done in order to meet different operating environments.

  • Multi-layer composite material to achieve gradient filtering effect, increasing the dust loading capacity and extending service life.
  • Low-resistance filter material, low energy consumption, fast air circulation.

Product Technical Specification

TypeBasic Weight
g/m²
Thickness
mm
Resistance
Pa
Efficiency
%
Carbon Content
g/m²
HY-T2002601710200
HY-JT200-653301.6865200
HY-JT200-9032521590200
HY-JT200-9532521795200
HY-JT200-9932522299200

Test Method: TSI 8130 NaCl, 0.3µm@32 L/min, 100cm²

Please Note:

Customized specifications as per the requirements are welcomed

Maximal Width: 1600mm

JT-Electrostatic cotton with active carton

Test Method: GSI 8130 NaCl, 0.3µm@32 L/min, 100cm² Note: Welcome the customized specifications Maximal Width: 1600mm JT-Electrostatic cotton with active carton
